Cooling Tower Fills Forming Machine

Usage:
This vacuum forming machine is widely used for making vacuum formed products like cooling tower fills from PVC, PS, PET and so on.
Operation Principle:
Operation processes: The heated and soften plastic sheet are being vacuum formed in the mold in order to get the various finished products. The operation processes are: sheet-feeding—heated—forming—side trimming— crosscut.
Structure feature:
01. The machine is combined with pneumatic , mechanical and electricity driving, adopt by PLC control . It can achieve sheet feeding , heating , forming , side trimming , crosscut into continuous job .
All working action can adjust under non-stop production . It’s convenient and high capacity , easy for operation .
02. The working method can crosscut by different pattern of fill .
03. Servo Motor feeding , Feeding Length stepless adjustable , precision and reliable.
04. Cutting Unit with Servo Motor Driving , Electrical & Pneumatic adjustable by different length crosscut ( the length must be longer than each forming mold length ) .
05. Forming area is big and easy for mold installation & replace.
06. Cylinder Roll Sheet Loading , Feeding Chain manual adjust.
07. Upper , Lower mold stroke limited , Up mold descend motor adjust.
08. Forming area double adjustable , can save the sheet material .
09. Back acting plate adopt double cylinder method , motor setting position .
10. Two steps of Vacuum .
11. Fan Blowing , Air Spray Cooling Device .
12. Heater adopt individual heating temperature control .
13. Advance sheet feeding , heating parameter can automatic adjust.

---
