Description
Model SJBHM-65/75/65-1800
Suitable material LDPE/LLDPE/mLLDPE/EVA and Mixing
Film layer 3 layers
Film thickness 0.02 - 0.18mm
Max film width 1600mm
Max output 200-300kg/h
Screw diameter φ65/φ75/φ65
Screw L/D ratio 32:1
Die head diameter φ300mm/400mm
Air ring Diameter φ350mm/450mm
Main motor power 37kw*1? 30kw*2
IBC system ?P+F probe and IBC system
EPC system EPC auto edge position control system
Screen changer Non-disassemble manual screen changer
Winding method Automatic back to back surface friction winder
Tension control system ?Auto
Overall? Dimension(L*W*H) 12000*7000*11500mm
Suitable material LDPE/LLDPE/mLLDPE/EVA and Mixing
Film layer 3 layers
Film thickness 0.02 - 0.18mm
Max film width 1600mm
Max output 200-300kg/h
Screw diameter φ65/φ75/φ65
Screw L/D ratio 32:1
Die head diameter φ300mm/400mm
Air ring Diameter φ350mm/450mm
Main motor power 37kw*1? 30kw*2
IBC system ?P+F probe and IBC system
EPC system EPC auto edge position control system
Screen changer Non-disassemble manual screen changer
Winding method Automatic back to back surface friction winder
Tension control system ?Auto
Overall? Dimension(L*W*H) 12000*7000*11500mm
