Description
1.Printing material：OPP/BOPP/CPP/PET/PE/PVC and rolled paper，etc.
2.Machine printing speed: 300-500 meters/minute.
3.The main machine adopts: servo motor drive.
4.Rotogravure cylinder loading: shaftless gravure cylinder loading.
(equipped with a pre-registration system for quick alignment and registration printing).
5.Transmission: Each color servo motor independent drive(electronic shaft).
6.Rewinding and unwinding traction adopts: Servo motor full automatically tension control.
7.Rewinding and unwinding adopt: dual-station high-speed non-stop automatic splicing and roll changing, servo motor drive, material change warning, shaftless pneumatic top-loading and unloading for quick replacement and precise centering, rotary arm automatically flips and positions during splicing, and the cutter frame has a reset function in case of emergency.
8.The four-section closed-loop tension system, motion control, and servo drive control are centrally managed by a PLC.
9.Heating method: new type of wind reduction and concentration-enhancing heating system with secondary air recirculation for heat energy utilization and automatic constant temperature control.
10.Use high-speed photography to monitor quality.
11.Each group of printing is independent.
12.Rewinding and unwinding diameter: 800mm.
13.Color Regjister adopts:automatic color register system，color registration accuracy?0.1mm.
14.The dual unwinding shafts are independently controlled and driven by two servo motors, with active dual-shaft unwinding regulated by vector frequency control.
15.The inking device adopts: drop roller,reducing ink splashing.
16.Widely used in: food packaging, daily chemical packaging, labels, pharmaceutical packaging, aluminum foil, etc.
2.Machine printing speed: 300-500 meters/minute.
3.The main machine adopts: servo motor drive.
4.Rotogravure cylinder loading: shaftless gravure cylinder loading.
(equipped with a pre-registration system for quick alignment and registration printing).
5.Transmission: Each color servo motor independent drive(electronic shaft).
6.Rewinding and unwinding traction adopts: Servo motor full automatically tension control.
7.Rewinding and unwinding adopt: dual-station high-speed non-stop automatic splicing and roll changing, servo motor drive, material change warning, shaftless pneumatic top-loading and unloading for quick replacement and precise centering, rotary arm automatically flips and positions during splicing, and the cutter frame has a reset function in case of emergency.
8.The four-section closed-loop tension system, motion control, and servo drive control are centrally managed by a PLC.
9.Heating method: new type of wind reduction and concentration-enhancing heating system with secondary air recirculation for heat energy utilization and automatic constant temperature control.
10.Use high-speed photography to monitor quality.
11.Each group of printing is independent.
12.Rewinding and unwinding diameter: 800mm.
13.Color Regjister adopts:automatic color register system，color registration accuracy?0.1mm.
14.The dual unwinding shafts are independently controlled and driven by two servo motors, with active dual-shaft unwinding regulated by vector frequency control.
15.The inking device adopts: drop roller,reducing ink splashing.
16.Widely used in: food packaging, daily chemical packaging, labels, pharmaceutical packaging, aluminum foil, etc.
